Peripheral
Accessory Port
Ronin Series Accessories (RSA)/NATO Ports
1/4"-20 Mounting Hole
Cold Shoe
Camera Control Port (USB-C)
Multifunctional Port (USB-C)
Battery
Model: BHX715-2150-15.48
Type: LiPo 4S
Capacity: 2150 mAh
Energy: 33.29 Wh
Voltage: 11.2 V to 17.8 V
USB Input: 5 V/3 A, 9 V/3 A, 12 V/3 A, 15 V/3 A, 20 V/3 A
Max Standby Time: Approx. 14 hours*
Charging Time: Approx. 1 hour**
Suggested Charging Temperature: 5° to 40° C (41° to 104° F)
* The 14-hour standby time is achieved with the DJI RS BG33 Battery Grip. The DJI RS BG33 Battery Grip is not available for purchase in India. This data is measured with the gimbal balanced in a level and stationary state. When the gimbal is in motion, the operating time will be reduced.
** Measured at an ambient temperature of 25° C (77° F) using a 65W charger supporting PD protocol to fully charge the DJI RS BG33 Battery Grip. The DJI RS BG33 Battery Grip is not available for purchase in India.
Connections
Bluetooth 5.0
USB-C Charging Port
Ronin App Requirements
iOS 14.0 or above
Android 9.0 or above
Languages Supported by the Touchscreen
English, Simplified Chinese, Traditional Chinese, German, French, Korean, Japanese, Spanish, Portuguese (Brazil), Russian, Thai
Working Performance
Tested Payload
3.0 kg (6.6 lbs)
Maximum Controlled Rotation Speed
Pan: 360°/s
Tilt: 360°/s
Roll: 360°/s
Mechanical Range
Pan Axis: 360° continuous rotation
Roll Axis: -95° to +240°
Tilt Axis: -112° to +214°
Axis Lock
Auto
Vertical Shooting
Supported
Mechanical & Electrical Properties
Operating Frequency
2.4000-2.4835 GHz
Bluetooth Transmitter Power
< 8 dBm
Operating Temperature
-20° to 45° C (-4° to 113° F)
Weight
Gimbal: Approx. 1193 g (2.63 lbs) (including the Upper and Lower Quick-Release Plates and screws)
Grip: Approx. 274 g (0.6 lbs)
Quick-Open Tripod: Approx. 149 g (0.3 lbs)
Upper and Lower Quick-Release Plates: Approx. 93 g (0.21 lbs) (including screws)
Dimensions
Folded: 247.4×115.7×258.7 mm (L×W×H, excluding camera, grip, and the Quick-Open Tripod)
Unfolded: 223.2×192.2×418.8 mm (L×W×H, including grip, excluding camera and the Quick-Open Tripod)
Accessories
DJI RS Enhanced Intelligent Tracking Module
Weight: Approx. 19 g (0.04 lbs)
Dimensions: 35.9×17.5×38.5 mm (L×W×H)
Tracking Distance: 0.5-10 m
Operating Environment: Illuminance > 20 lux
Trigger Methods: Gimbal trigger, gesture, gimbal touchscreen
Gesture Functions: Start/stop of tracking, start/stop of recording, framing adjustment
Power Consumption: Approx. 1 W
Operating Temperature: -10° to 45° C (14° to 113° F)
Mounting Method: Magnetic attachment
Electronic Briefcase Handle
Weight: Approx. 230 g (0.51 lbs)
Dimensions: 60×197.5×79.5 mm (L×W×H)
Standby Power Consumption: Approx. 0.2 W
Operating Temperature: -20° to 45° C (-4° to 113° F)
